Do you know CNC lathe machine?

CNC mini lathe is a kind of CNC lathe metal, which fixes the work piece on the main shaft and rotates at high speed to process the cutting tool in feed motion.

Automatic CNC lathe is a machine tool that is driven by an electric motor to rotate the spindle through a belt and gear transmission system, china CNC lathe drives the workpiece on the spindle chuck to rotate, and then uses the turning tool fixed on the tool holder for turning.

The main work piece is round rods. The cutting work includes turning end face, inner and outer diameter, arc, taper, drilling, boring, eccentricity, embossing, cutting, grooving, turning thread.

Structure of cnc horizontal lathe

1. Total Inventory of cnc lathe flat bed

CNC metal lathe includes main shaft, main shaft gear transmission mechanism and external gear train.

The spindle of high precision cnc lathe: install the chuck to hold the workpiece; the spindle gear transmission mechanism of heavy duty cnc lathe machine: drive the spindle to rotate and change speed; the external gear train of cnc lathe machine horizontal: drive the feed for automatic feeding and thread turning .

2. Bed by turning machine cnc lathe

The bed of cnc lathe machine metal is made of cast iron to support the spindle head, tool slide, and tailstock. The slide rail on the cnc lathe machine is composed of a flat rail and a V rail, providing precise sliding of the tool slide seat and the tail seat.

3.Tool-Carriage Assembly of cnc lathe machine mini

The tool holder of cnc mini metal lathe can hold different types of turning tools and gauge holders.

4. Tail Stock of cnc lathe mini

It is used to install drill clamps or taper shank drills for drilling center holes, drilling, tapping, and reaming. Used to install the top center.
