The protective cover of cnc lathe manufacture has the characteristics of tight structure, reasonable, no noise, large stroke, fast movement and long service life.
Used in common machine tools, CNC machine tools, hydraulic machinery and other equipment. The operating environment of the flat bed cnc lathe machine can also be made into steel support frame, wood frame, PVC frame, cold plate frame, organ shield, etc. According to the operating environment of the mini cnc lathe machine, the internal structure of the organ shield includes grooves, rollers, nylon sliders, sliders, tension bars, tension springs, and nylon shafts.
It includes a cover body, a support ring, a support plate and two connecting bars. The cover body is made of soft insulating material. The cover body is in the shape of a circular cone. The arc wall of the cover body is provided with a telescopic groove along the axial direction. Both sides are respectively provided with a connecting bar extending outward along the radial direction of the cover body, the opposite surfaces of the two connecting bars are the inner side, and the opposite surface is the outer side, each connecting bar is provided with a connecting device, and the supporting ring It is fixed on the outer side wall of one of the connecting bars, and the support plate is movably arranged between the two connecting bars.
The main body is composed of chain plates, support plates, shaft pins and other components, so that there is no relative movement between the cable or rubber tube and the drag chain, and no distortion occurs. High, good elasticity, easy to install, reliable to use, easy to disassemble.
